■ LC series / 20-80W

Product Feature

Output Power Range: 20-80W
Mode: CC Non-isolation Flicker-free
Type: Iron clad structure, IP20
Current selection 4 steps, by DIP
Color temperature switchable. (K version)
Surge protection level: DM 1 kV, CM 2 kV
Protection: No-Load / Short Circuit / Overload/ Non-SELV / ClassⅠ
Start time:≤0.5s (230VAC, full load)
Ambient Temp: -20-65℃
Storage Temp: -25-85℃
Warranty: 5 Years

■ Product Parameter:

Model	Power	Input Voltage	Output Voltage	Output Current Range	Efficiency	Power Factor	Size (mm) (LWH)
AND-W20C035-LC	20W	220-240Vac	24-105V	0.2 / 0.25 /0.3 / 0.35A	≥89%	≥0.95	1653021
AND-W40C035-LC	40W	220-240Vac	50-200V	0.2 / 0.25 /0.3 / 0.35A	≥92%	≥0.95	1653021
AND-W60C035-LC	60W	220-240Vac	50-220V	0.2 / 0.25 /0.3 / 0.35A	≥93%	≥0.95	1653021
AND-W75C055-LC	75W	220-240Vac	90-216V	0.35 / 0.4 / 0.5 / 0.55A	≥94%	≥0.95	2103021

■ Application :

Linear light, Tri-proof light

■ Safety Certification:
