| AC input voltage range | AC100-305V |
| Rated Power (max) | 240W |
| Output Voltage | 100-143V |
| Output Current | 1.6~2.4A Regulation by potentionmeter |
| Short circuit protection | Auto recovery mode |
| Dielectric withstand voltage | I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC |
| Operation temperature | -40 ～+55℃ @ full load ; +70℃ @ 60% load |
| Safety standard |
UL1012 ; EN61347-1, EN61347-2-13 independent Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547, light industry level (surge immunity Line-Earth 10KV, Line-Line 5KV)
|
| EMC standard |
EN55015, EN55022 (CISPR22) Class B EN61000-4-2,3,4,5,6,8,11; ENV50204, EN61547, EN55024 |
| Size | 195*68*36.5mm (L*W*H), 840g/pc |
| Model | Output voltage | Output current | Current tolerance | Efficiency | PF |
|---|---|---|---|---|---|
| AND-TP-240S042Y | 27-42V | 5.7~8.0A | ±3% | ≥92% | ≥0.95 |
| AND-TP-240S084Y | 54-84V | 2.8~4.4A | ±3% | ≥92% | ≥0.95 |
| AND-TP-240S214Y | 143-214V | 1.1~1.68A | ±3% | ≥92% | ≥0.95 |
