| AC input voltage range | AC220-240V |
| Rated Power | 65W |
| Output Voltage | 110-185V |
| Output Current | 200-350mA |
| Short circuit protection | Auto recovery mode |
| Dielectric withstand voltage | I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC |
| Operation temperature | -15 ～+55℃ @ full load ; +70℃ @ 60% load |
| Safety standard |
UL1012 ; EN61347-1, EN61347-2-13 independent UL60950-1, TUV EN60950-1 (TBD) CQC/CCC: GB 19510.14-2009 Surge: IEC/EN61000-4-5 |
| EMC standard |
EN55015, EN55022 (CISPR22) Class B EN61000-4-2,3,4,5,6,8,11; ENV50204, EN61547, EN55024 |
| Size | Plastic case: 173.5(L) / 217.5(L)*25.3(W)*20.5(H)mm |
| Model | Output voltage | Output current | Current tolerance | Efficiency | PF |
|---|---|---|---|---|---|
| AND-45W200N-C03 | 120-225V | 100-200mA | ±5% | ≥90% | ≥0.95 |
| AND-45W300N-C03 | 80-150V | 200-300mA | ±5% | ≥90% | ≥0.95 |
| AND-65W350N-C03 | 110-185V | 200-350mA | ±5% | ≥90% | ≥0.95 |
